ISL95870BIRZ Integrated Circuit Chip PWM DC/DC Controller With VID Inputs For Portable GPU Core-Voltage Regulator
ISL95870BIRZ Integrated Circuit Chip PWM DC/DC Controller With VID Inputs For Portable GPU Core-Voltage Regulator
Description
Part Number:
ISL95870BIRZ
Number Of Outputs::
1 Output
Switching Frequency::
300 KHz To 1 MHz
Output Voltage::
500 MV To 5 V
Output Current::
30 A
Unit Weight::
32.500 Mg
ISL95870BIRZ Integrated Circuit Chip PWM DC/DC Controller With VID Inputs For Portable GPU Core-Voltage Regulator
Product Description Of ISL95870BIRZ
ISL95870BIRZ is Single-Phase Synchronous-Buck PWM regulators featuring Intersil’s proprietary R4 Technology™. The wide 3. 3V to 25V input voltage range is ideal for systems that run on battery or AC-adapter power sources. TheISL95870BIRZ is low-cost solutions for applications requiring dynamically selected slew-rate controlled output voltages.
Specification Of ISL95870BIRZ
1 Output
300 kHz to 1 MHz
500 mV to 5 V
30 A
- 40 C
+ 100 C
Height:
0.9 mm
Length:
4 mm
Width:
3 mm
Unit Weight:
32.500 mg
Features Of ISL95870BIRZ
Input Voltage Range: 3.3V to 25V
Output Voltage Range: 0.5V to 5V
Precision Regulation
Proprietary R4™ Frequency Control Loop
±0.5% System Accuracy Over -10°C to +100°C
Optimal Transient Response
Intersil’s R4™ Modulator Technology
Output Remote Sense
Extremely Flexible Output Voltage Programmability
2-Bit VID Selects Four Independent Setpoint Voltages for ISL95870B
Simple Resistor Programming of Setpoint Voltages
Selectable 300kHz, 500kHz, 600kHz or 1MHz PWM Frequency in Continuous Conduction
Automatic Diode Emulation Mode for Highest Efficiency
Power-Good Monitor for Soft-Start and Fault Detection
Applications Of ISL95870BIRZ
Mobile PC Graphical Processing Unit VCC Rail
Mobile PC I/O Controller Hub (ICH) VCC Rail
Mobile PC Memory Controller Hub (GMCH) VCC Rail
