Product Description Of OPA2191IDR
OPA2191IDR is a new generation of 36-V, e-trim™ operational amplifiers.
OPA2191IDR offer outstanding dc precision and ac performance, including rail-to-rail input/output, low offset voltage (±5 µV, typ), low offset drift (±0.2 µV/°C, typ), and 2-MHz bandwidth.
Unique features, such as differential input-voltage range to the supply rail, high output current (±65 mA), high capacitive load drive of up to 1 nF, and high slew rate (5 V/µs), make the OPAx191 a robust, high-performance operational amplifier for high-voltage industrial applications.
OPA2191IDR op amps is available in standard packages and is specified from –40°C to +125°C.
Specification Of OPA2191IDR
2 Channel
2.5 MHz
5.5 V/us
25 uV
20 pA
36 V
4.5 V
140 uA
65 mA
140 dB
15 nV/sqrt Hz
- 40 C
+ 125 C
Features:
EMI Hardened, High Cload Drive
In - Input Noise Current Density:
1.5 fA/sqrt Hz
Input Type:
Rail-to-Rail
Ios - Input Offset Current:
2 nA
Maximum Dual Supply Voltage:
+/- 18 V
Minimum Dual Supply Voltage:
+/- 2.25 V
THD plus Noise:
0.0012 %
Unit Weight:
84.500 mg
Features Of OPA2191IDR
Low offset voltage: ±5 µV
Low offset voltage drift: ±0.1 µV/°C
Low noise: 15 nV/√ Hz at 1 kHz
High common-mode rejection: 140 dB
Low bias current: ±5 pA
Rail-to-rail input and output
Wide bandwidth: 2.5-MHz GBW
High slew rate: 5 V/µs
Low quiescent current: 140 µA per amplifier
Wide supply: ±2.25 V to ±18 V, 4.5 V to 36 V
EMI/RFI filtered inputs
Differential input voltage range to supply rail
High capacitive load drive capability: 1 nF
Applications Of OPA2191IDR
Analog input module
Mixed module (AI, AO, DI, DO)
Data acquisition (DAQ)
Source measurement unit (SMU)
Pressure transmitter
Train control and management systems
Lab and field instrumentation
