Product Description Of LT1168CS8

LT1168CS8 is a micropower, precision instrumentation amplifier that requires only one external resistor to set gains of 1 to 10,000. The low voltage noise of 10nV/√Hz (at 1kHz) is not compromised by low power dissipation (350µA typical for ±15V supplies). The wide supply range of ±2.3V to ±18V allows the LT1168CS8 to fit into a wide variety of industrial as well as battery-powered applications.

Specification Of LT1168CS8

Features Of LT1168CS8

Supply Current: 530µA Max
Meets IEC 1000-4-2 Level 4 (±15kV) ESD Tests with Two External 5k Resistors
Single Gain Set Resistor: G = 1 to 10,000
Gain Error: G = 10, 0.4% Max
Input Offset Voltage Drift: 0.3µV/°C Max
Gain Nonlinearity: G = 10, 20ppm Max
Input Offset Voltage: 40µV Max
Input Bias Current: 250pA Max
PSRR at AV =1: 103dB Min
CMRR at AV = 1: 90dB Min
Wide Supply Range: ±2.3V to ±18V
1kHz Voltage Noise: 10nV/√Hz
0.1Hz to 10Hz Noise: 0.28µVP-P

Applications Of LT1168CS8
Bridge Amplifiers
Strain Gauge Amplifiers
Thermocouple Amplifiers
Differential to Single-Ended Converters
Differential Voltage to Current Converters
Data Acquisition
Battery-Powered and Portable Equipment
Medical Instrumentation
Scales
