TPS25200DRVR Integrated Circuit Chip 5V eFuse With Precision Adjustable Current Limit And Overvoltage Clamp

TPS25200DRVR Integrated Circuit Chip 5V eFuse With Precision Adjustable Current Limit And Overvoltage Clamp

Product Description Of TPS25200DRVR
TPS25200DRVR is a 5V eFuse with precision current limit and overvoltage clamp. The device provides robust protection for load and source during overvoltage and overcurrent events.

TPS25200DRVR is an intelligent protected load switch with VIN tolerant to 20V. In the event that an incorrect voltage is applied at IN, the output clamps to 5.4V to protect the load. If the voltage at IN exceeds 7.6V, the device disconnects the load to prevent damage to the device and/or load.

TPS25200DRVR has an internal 60mΩ power switch and is intended for protecting source, device, and load under a variety of abnormal conditions. The device provides up to 2.6A of continuous load current. Current limit is programmable from 85mA to 2.9A with a single resistor to ground. During overload events output current is limited to the level set by RILIM. If a persistent overload occurs the device eventually goes into thermal shutoff to prevent damage to the TPS25200DRVR.

Specifications Of TPS25200DRVR

Features Of TPS25200DRVR
2.5V to 6.5V operation
Input withstands up to 20V
7.6V input overvoltage shutoff
5.25V to 5.55V fixed overvoltage clamp
0.6µs overvoltage lockout response
3.5µs short circuit response
Integrated 60mΩ high-side MOSFET
Up to 2.6A continuous load current
±6% current-limit accuracy at 2.9A
Reverse current blocking while disabled
Built-in soft start
Pin-to-pin compatible with TPS2553

Applications Of TPS25200DRVR
USB power switches
USB target devices
Cell, smart phones
3G, 4G wireless data cards
Solid-state drives (SSD)
3V or 5V adapter powered devices
