Product Description Of OPA2171AQDGKRQ1
OPA2171AQDGKRQ1 devices is a 36-V, singlesupply, low-noise operational amplifier (op amp) with the ability to operate on supplies ranging from 2.7 V (±1.35 V) to 36 V (±18 V). This series is available in multiple packages and offers low offset, drift, and low quiescent current. The single, dual, and quad versions all have identical specifications for maximum design flexibility.
Specifications Of OPA2171AQDGKRQ1
2 Channel
3 MHz
1.5 V/us
1.8 mV
15 pA
36 V
4.5 V
475 uA
25 mA
120 dB
14 nV/sqrt Hz
- 40 C
+ 125 C
Ios - Input Offset Current:
4 pA
THD plus Noise:
0.0002 %
Vcm - Common Mode Voltage:
2.6 V to 34 V
Unit Weight:
30 mg
Features Of OPA2171AQDGKRQ1
Qualified for automotive applications
AEC-Q100 test guidance with the following results:
Temperature grade 1: –40°C to +125°C ambient operating temperature
Device HBM ESD classification level:
Level 3A forOPA171-Q1
Level 2 for OPA4171-Q1
Device CDM ESD classification level
Level C4A for OPA171-Q1TLV171-Q1
Level C6 for OPA2171-Q1
Level C6 for OPA4171-Q1
Supply range:
Single-supply: 2.7 V to 36 V
Dual-supply ±1.35 V to ±18 V
Low noise: 14 nV/√Hz at 1 kHz
Low offset drift: ±0.3 µV/°C (typical)
Input range includes negative supply
Input range operates to positive supply with reduced performance
Rail-to-rail output
Gain bandwidth: 3 MHz
Low quiescent current: 475 µA per amplifier
High Common-mode rejection: 120 dB (typical)
Low input bias current: 10 pA
Industry-Standard Package:
5-Pin Small-Outline Transistor SOT-23 (DBV) Package
Applications Of OPA2171AQDGKRQ1
Tracking amplifier in power modules
Merchant power supplies
Transducer amplifiers
Bridge amplifiers
Temperature measurements
Strain gauge amplifiers
Precision integrators
Battery-powered instruments
Test equipment
