MAX3223EUP Integrated Circuit Chip 250kbps RS-232 Transceivers With AutoShutdown

MAX3223EUP Integrated Circuit Chip 250kbps RS-232 Transceivers With AutoShutdown
MAX3223EUP Integrated Circuit Chip 250kbps RS-232 Transceivers With AutoShutdown

Large Image :  MAX3223EUP Integrated Circuit Chip 250kbps RS-232 Transceivers With AutoShutdown

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MAX3223EUP
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSSOP-20
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

MAX3223EUP Integrated Circuit Chip 250kbps RS-232 Transceivers With AutoShutdown

Description
Part Number: MAX3223EUP Type: Transceiver
Protocol: RS232 Number Of Drivers/Receivers: 2/2
Receiver Hysteresis: 300 MV Data Rate: 120Kbps

MAX3223EUP Integrated Circuit Chip 250kbps RS-232 Transceivers With AutoShutdown



Product Overviews Of MAX3223EUP

MAX3223EUP is 3V-powered EIA/TIA-232 and V.28/V.24 communications interfaces with automatic shutdown/wakeup features, high data-rate capabilities, and enhanced electrostatic discharge (ESD) protection.

MAX3223EUP transceivers have a proprietary low-dropout transmitter output stage, delivering true RS-232 performance from a +3.0V to +5.5V supply with a dual charge pump. The charge pump requires only four small 0.1µF capacitors for operation from a +3.3V supply. Each device is guaranteed to run at data rates of 250kbps while maintaining RS-232 output levels.


Specification Of MAX3223EUP

Part Number: MAX3223EUP
Product Category: RS-232 Interface IC
TSSOP-20
Transceiver
120 kb/s
2 Driver
2 Receiver
Full Duplex
5.5 V
3 V
SMD/SMT
1 mA
- 40 ℃
+ 85 ℃
Without ESD Protection
Operating Supply Voltage: 3.3 V, 5 V
Product: RS-232 Transceivers
Product Type: RS-232 Interface IC
Propagation Delay Time: 0.3 us
Shutdown: With Shutdown


Features Of MAX3223EUP

Integrated Charge Pump Circuitry Simplifies Power Requirements
- Eliminates the Need for a ±12 Supply
- Operation From a Single +3.3V or +5V Supply
1µA Supply Current in Shutdown Mode Saves Power
- AutoShutdown Feature is Enabled After No Activity on Receiver Inputs for 30µs
- Software Control Option for Shutdown


Applications Of MAX3223EUP
Battery-Powered Equipment
Cell Phones
Handheld Equipment
Notebook, Subnotebook, and Palmtop Computers
Peripherals
Printers
