INA169NA/3K Integrated Circuit Chip 2.7 To 60V 440kHz Variable Gain Current Sense Amplifier
INA169NA/3K Integrated Circuit Chip 2.7 To 60V 440kHz Variable Gain Current Sense Amplifier
Description
Part Number:
INA169NA/3K
Sensing Method::
High Side
Supply Voltage - Max::
60 V
Supply Voltage - Min::
2.7 V
Operating Supply Current::
125 UA
Accuracy::
0.5 %
INA169NA/3K Integrated Circuit Chip 2.7 To 60V 440kHz Variable Gain Current Sense Amplifier
Product Description Of INA169NA/3K
INA169NA/3K is high-side, unipolar, current shunt monitors. Wide input common-mode voltage range, high-speed, low quiescent current, and tiny SOT-23 packaging enable use in a variety of applications.
Specifications Of INA169NA/3K
High Side
60 V
2.7 V
125 uA
0.5 %
- 40 C
+ 125 C
Bandwidth:
4400 kHz
Gain:
1 V/V to 100 V/V
Ib - Input Bias Current:
10 uA
Input Voltage Range:
2.7 V to 60 V
Moisture Sensitive:
Yes
Vos - Input Offset Voltage:
1 mV
Unit Weight:
770 mg
Features Of INA169NA/3K
Complete Unipolar High-Side Current Measurement Circuit
Wide Supply and Common-Mode Range
INA139: 2.7 V to 40 V
INA169: 2.7 V to 60 V
Independent Supply and Input Common-Mode Voltages
Single Resistor Gain Set
Low Quiescent Current: 60 µA (Typical)
5-Pin, SOT-23 Packages
Applications Of INA169NA/3K
Current Shunt Measurement:Automotive, Telephone, Computers
Portable and Battery-Backup Systems
Battery Chargers
Power Management
Cell Phones
Precision Current Source
