TL5209DR Integrated Circuit Chip 500mA Low-Noise Low-Dropout Voltage Regulator With Shutdown
TL5209DR Integrated Circuit Chip 500mA Low-Noise Low-Dropout Voltage Regulator With Shutdown
Description
Part Number:
TL5209DR
Output Voltage::
6.5 V
Output Current::
500 MA
Number Of Outputs::
1 Output
Polarity::
Positive
Quiescent Current::
140 UA
TL5209DR Integrated Circuit Chip 500mA Low-Noise Low-Dropout Voltage Regulator With Shutdown
Product Description Of TL5209DR
TL5209DR is 500-mA low-dropout (LDO) regulator that is well suited for portable applications. It has a lower quiescent current than most traditional PNP regulators and allows for a shutdown current of 0.05 µA (typical). The TL5209DR also has very good dropout voltage characteristics, requiring a maximum dropout of 10 mV at light loads and 500 mV at full load. In addition, the LDO also has a 1% output voltage accuracy and very tight line and load regulation that is comparable to its CMOS counterparts.
Specifications Of TL5209DR
6.5 V
500 mA
1 Output
Positive
140 uA
2.5 V
16 V
Fixed
- 40 C
+ 125 C
500 mV
Dropout Voltage - Max:
60 mV
Height:
1.58 mm
Ib - Input Bias Current:
100 uA
Length:
4.9 mm
Line Regulation:
0.05 % / V
Load Regulation:
0.5 %
Operating Supply Current:
8 mA
Voltage Regulation Accuracy:
1 %
Width:
3.91 mm
Unit Weight:
170 mg
Features Of TL5209DR
Adjustable Output Voltage
1%/2% Accuracy (25°C/Full Range)
500-mV (Maximum) Dropout at Full Load of 500 mA
Tight Regulation Overtemperature Range
0.1%/V (Maximum) Line Regulation
0.7% (Maximum) Load Regulation
Ultra Low-Noise Capability (300 nV/√Hz Typical)
Shutdown Current of 3 µA (Maximum)
Low Temperature Coefficient
Current Limiting and Thermal Protection
Stable With Minimum Load of 1 mA
Reverse-Battery Protection
Available in Convenient SOIC-8 Surface-Mount Package
Applications Of TL5209DR
Set-Top Boxes
PCs and Notebooks
EPOS
Building Automation
Consumer Electronics
Post-Regulation for SMPS
