LT3050EDDB-3.3 Integrated Circuit Chip 100mA Linear Regulator With Precision Current Limit And Diagnostic Outputs

LT3050EDDB-3.3 Integrated Circuit Chip 100mA Linear Regulator With Precision Current Limit And Diagnostic Outputs

Product Description Of LT3050EDDB-3.3
LT3050EDDB-3.3 is micro-power, low noise, low dropout voltage (LDO) linear regulators. The devices supply 100mA of output current with a dropout voltage of 340mV. A 10nF bypass capacitor reduces output noise to 30μVRMS in a 10Hz to 100kHz bandwidth and soft-starts the reference. The LT3050EDDB-3.3’s ±45V input voltage rating combined with its precision current limit and diagnostic functions make the IC an ideal choice for robust, high reliability applications.

Specicication Of LT3050EDDB-3.3

Features Of LT3050EDDB-3.3
Output Current Monitor: 1/100th of IOUT
Fault Indicator: Current Limit, Minimum IOUT or Thermal Limit
Output Current: 100mA
Dropout Voltage: 340mV
Input Voltage Range: 1.6V to 45V
Programmable Precision Current Limit: ±5%
Programmable Minimum IOUT Monitor
Low Noise: 30μVRMS (10Hz to 100kHz)
Adjustable Output (VREF = VOUT(MIN) = 0.6V)
Fixed Output Voltages: 3.3V, 5V
Output Tolerance: ±2% Over Line, Load and Temperature
Stable with Low ESR, Ceramic Output Capacitors (2.2μF minimum)
Shutdown Current: <1μA
Reverse-Battery, Reverse-Output and Reverse-Current Protection
Thermal Limit Protection
12-Lead 3mm × 2mm DFN and MSOP Packages

Applications Of LT3050EDDB-3.3
Protected Antenna Supplies
Automotive Telematics
Industrial Applications (Trucks, Forklifts, etc.)
High Reliability Applications
