Part Number: | CDCE6214RGET | Type: | Clock Generator |
---|---|---|---|
Frequency - Max: | 350MHz | Ratio - Input:Output: | 2:4 |
Voltage - Supply: | 1.71V ~ 3.465V | Operating Temperature: | -40°C ~ 85°C |
CDCE6214RGET Integrated Circuit Chip 350MHz Ultra Low Power Clock Generators VQFN24
Product Overviews Of CDCE6214RGET
CDCE6214RGET is a four-channel, ultra-low power, medium grade jitter, clock generator that can generate five independent clock outputs selectable between various modes of drivers. The input source can be a single-ended or differential input clock source, or a crystal.
CDCE6214RGET features a frac-N PLL to synthesize unrelated base frequency from any input frequency. The CDCE6214RGET can be configured through the I2C interface. In the absence of the serial interface, the GPIO pins can be used in Pin Mode to configure the product into distinctive configurations.
Specification Of CDCE6214RGET
Part Number: | CDCE6214RGET |
Clock Generator | |
4 Output | |
350 MHz | |
200 MHz | |
VQFN-24 | |
55 % | |
1600 fs | |
3.465 V | |
1.71 V | |
394 A | |
- 40 ℃ | |
+ 105 ℃ | |
Operating Supply Voltage: | 1.71 V to 3.465 V |
Output Type: | HCSL, LVCMOS, LVDS |
Features Of CDCE6214RGET
Configurable high performance, low-power, frac-N PLL with RMS jitter with spurs (12kHz – 20MHz, Fout > 100MHz) as:
Integer mode:
Differential output: 350fs typical (typ.), 600fs maximum (max)
LVCMOS output: 1.05ps typ., 1.5ps max
Fractional mode:
Differential output: 1.7ps typ., 2.1ps max
LVCMOS output: 2.0ps typ., 4.0ps max
Supports PCIe Gen1/2/3/4 with SSC and Gen 1/2/3/4/5/6 without SSC
Typ. power consumption: 65mA for 4-output channel, 23mA for 1-output channel.
Universal clock input
Differential AC-coupled or LVCMOS: 10MHz to 200MHz
Crystal: 10MHz to 50MHz
Flexible output clock distribution
Four channel dividers: Up to five unique output frequencies from 24kHz to 328.125MHz
Combination of LVDS-like, LP-HCSL or LVCMOS outputs on OUT0 – OUT4 pins
Glitchless output divider switching and output channel synchronization
Individual output enable through GPIO and register
Fully-integrated, configurable loop bandwidth: 100kHz to 1.6MHz
Single or mixed supply for level translation: 1.8V, 2.5V, 3.3V
Configurable GPIOs and flexible configuration options
I2C-compatible interface: up to 400kHz
Integrated EEPROM with two pages and external select pin. In-situ programming allowed.
Supports 100Ω systems
Low electromagnetic emissions
Small footprint: 24-pin VQFN (4mm × 4mm)
