SI53152-A01AGMR Integrated Circuit Chip Spread Spectrum Tolerant PCIe Clock Buffer

SI53152-A01AGMR Integrated Circuit Chip Spread Spectrum Tolerant PCIe Clock Buffer

Product Description Of SI53152-A01AGMR
SI53152-A01AGMR is a spread spectrum tolerant PCIe clock buffer that can source two PCIe clocks simultaneously. The device has two hardware output enable inputs for enabling the respective differential outputs on the fly. The device also features output enable control through I2C communication. I2C programmability is also available to dynamically control skew, edge rate and amplitude on the true, compliment, or both differential signals on the clock outputs.

Specification Of SI53152-A01AGMR

Features Of SI53152-A01AGMR
PCI-Express Gen 1, Gen 2, Gen 3, and Gen 4 common clock compliant
Supports Serial ATA (SATA) at 100 MHz
100–210 MHz operation
Low power, push pull, differential output buffers
Internal termination for maximum integration
Dedicated output enable pin for each clock
Two PCI-Express buffered clock outputs
Supports LVDS outputs
I2C support with readback capabilities
Extended temperature:–40 to 85 °C
3.3 V Power supply
24-pin QFN package

Applications Of SI53152-A01AGMR
Network attached storage
Multi-function Printer
Wireless access point
Routers
