DS28E25P Memory IC Chip DeepCover Secure Authenticator With 1-Wire SHA-256 And 4Kb User EEPROM

DS28E25P Memory IC Chip DeepCover Secure Authenticator With 1-Wire SHA-256 And 4Kb User EEPROM

Product Description Of DS28E25P
DeepCover™ embedded security solutions cloak sensitive data under multiple layers of advanced physical security to provide the most secure key storage possible.

The DeepCover Secure Authenticator DS28E25P combines crypto-strong, bidirectional, secure challengeand- response authentication functionality with an implementation based on the FIPS 180-3-specified Secure Hash Algorithm (SHA-256). A 4Kb user-programmable EEPROM array provides nonvolatile storage of application data and additional protected memory holds a readprotected secret for SHA-256 operations and settings for user memory control.

Specifications Of DS28E25P

Features Of DS28E25P
Symmetric-Key-Based Bidirectional Secure Authentication Model Based on SHA-256
Dedicated Hardware-Accelerated SHA Engine for Generating SHA-256 MACs
Strong Authentication with a High Bit Count, User-Programmable Secret, and Input Challenge
4096 Bits of User EEPROM Partitioned Into 16 Pages of 256 Bits
User-Programmable and Irreversible EEPROM Protection Modes Including Authentication, Write and Read Protect, and OTP/EPROM Emulation
Unique, Factory-Programmed 64-Bit Identification Number
Single-Contact 1-Wire Interface Communicates with Host at Up to 76.9kbps
Operating Range: 3.3V ±10%, -40°C to +85°C
Low-Power 5µA (typ) Standby
±8kV HBM ESD Protection (typ)

Applications Of DS28E25P
Authentication of Network-Attached Appliances
Key Generation and Exchange for Cryptographic Systems
Printer Cartridge ID/Authentication
Reference Design License Management
Secure Feature Setting for Configurable Systems
Sensor/Accessory Authentication and Calibration
System Intellectual Property Protection
