Product Description Of ADG1401BRMZ
ADG1401BRMZ contain a single-pole/single-throw (SPST) switch. Figure 1 shows that with a logic input of 1, the switch of the ADG1401 is closed and that of the ADG1402 is open. Each switch conducts equally well in both directions when on and has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked.

Specifications Of ADG1401BRMZ

Features Of ADG1401BRMZ
1 Ω on resistance
0.2 Ω on resistance flatness
Up to 435 mA continuous current
8-lead MSOP and 8-lead, 3 mm × 2 mm LFCSP packages
No VL supply required
3 V logic-compatible inputs
Rail-to-rail operation
Fully specified at +12 V, ±15 V, ±5 V

Product Highlights Of ADG1401BRMZ
1.3 Ω maximum on resistance at 25°C.
Minimum distortion.
3 V logic-compatible digital inputs: VIH = 2.0 V, VIL = 0.8 V.
No VL logic power supply required.
8-lead MSOP and 8-lead, 3 mm × 2 mm LFCSP packages.

Applications Of ADG1401BRMZ
Automatic test equipment
Data acquisition systems
Battery-powered systems
Sample-and-hold systems
Audio signal routing
Video signal routing
Communication systems
Relay replacements
