ADPD4100BCBZR7 Integrated Circuit Chip Multimodal Sensor Front End 10µA Optical AFEs

ADPD4100BCBZR7 Integrated Circuit Chip Multimodal Sensor Front End 10µA Optical AFEs​

Product Overviews Of ADPD4100BCBZR7

ADPD4100BCBZR7 operate as a complete multimodal sensor front end, stimulating up to eight light emitting diodes (LEDs) and measuring the return signal on up to eight separate current inputs. Twelve time slots are available, enabling 12 separate measurements per sampling period.

Specification Of ADPD4100BCBZR7

Features Of ADPD4100BCBZR7

Multimodal analog front end
8 input channels with multiple operation modes for various sensor measurements
Dual-channel processing with simultaneous sampling
12 programmable time slots for synchronized sensor measurements
Flexible input multiplexing to support differential and single-ended sensor measurements
8 LED drivers, 4 of which can be driven simultaneously
Flexible sampling rate from 0.004 Hz to 9 kHz using internal oscillators
On-chip digital filtering
SNR of transmit and receive signal chain: 100 dB
AC ambient light rejection: 60 dB up to 1 kHz
400 mA total LED peak drive current
Total system power dissipation: 30 µW (combined LED and AFE power), continuous PPG measurement at 75 dB SNR, 25 Hz ODR, 100 nA/mA CTR
SPI communications supported
512-byte FIFO size

Applications Of ADPD4100BCBZR7
Wearable health and fitness monitors: heart rate monitors (HRMs), heart rate variability (HRV), stress, blood pressure estimation, SpO2, hydration, body composition
Industrial monitoring: CO, CO2, smoke, and aerosol detection
Home patient monitoring
