LT3060ETS8-5 Integrated Circuit Chip 45V Low Dropout Linear Regulator 100mA LDO Regulators

LT3060ETS8-5 Integrated Circuit Chip 45V Low Dropout Linear Regulator 100mA LDO Regulators

Product Overviews Of LT3060ETS8-5

LT3060ETS8-5 is micropower, low dropout voltage (LDO) linear regulators that operate over a 1.6V to 45V input supply range. LT3060ETS8-5 supply 100mA of output current with a typical dropout voltage of 300mV. A single external capacitor provides programmable low noise reference performance and output soft-start functionality.

LT3060ETS8-5’s quiescent current is merely 40μA and provides fast transient response with a minimum 2.2μF output capacitor. In shutdown, quiescent current is less than 1μA and the reference soft-start capacitor is reset.

LT3060ETS8-5 Regulators optimize stability and transient response with low ESR, ceramic output capacitors. The regulators do not require the addition of ESR as is common with other regulators.

Specification Of LT3060ETS8-5

Features Of LT3060ETS8-5

Input Voltage Range: 1.6V to 45V
Output Current: 100mA
Quiescent Current: 40μA
Dropout Voltage: 300mV
Low Noise: 30μVRMS (10Hz to 100kHz)
Adjustable Output: VREF = 600mV
Fixed Output Voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 15V
Output Tolerance: ±2% Over Line, Load and Temperature
Single Capacitor Soft-Starts Reference and Lowers Output Noise
Shutdown Current: < 1μA
Reverse Battery Protection
Current Limit Foldback Protection
Thermal Limit Protection

Applications Of LT3060ETS8-5
Battery-Powered Systems
Automotive Power Supplies
Industrial Power Supplies
Avionic Power Supplies
Portable Instruments
