NCP59748MN1ADJTBG Integrated Circuit Chip LDO Regulator 1.5A Low Dropout Regulators

NCP59748MN1ADJTBG Integrated Circuit Chip LDO Regulator 1.5A Low Dropout Regulators​

Product Description Of NCP59748MN1ADJTBG

NCP59748MN1ADJTBG is dual−rail very low dropout voltage regulator, capable of providing an output current in excess of 1.5A with a dropout voltage of 60 mV typ. at full load current.

NCP59748MN1ADJTBG is stable with ceramic and any other type of output capacitor ≥ 2.2 F. This series contains adjustable output voltage version with output voltage down to 0.8 V. Internal protection features consist of built-in thermal shutdown and output current limiting protection.

Specification Of NCP59748MN1ADJTBG

Features Of NCP59748MN1ADJTBG

Output Current in Excess of 1.5 A
VIN Range: 0.8 V to 5.5 V
VBIAS Range: 2.7 V to 5.5 V
Output Voltage Range: 0.8 V to 3.6 V
Dropout Voltage: 60 mV at 1.5 A
Programmable Soft-Start
Open Drain Power Good Output
Fast Transient Response
Stable with Any Type of Output Capacitor ≥ 2.2 F
Current Limit and Thermal Shutdown Protection

Typical Applications Of NCP59748MN1ADJTBG

Consumer and Industrial Equipment Point of Load Regulation
FPGA, DSP and Logic Power Supplies
Switching Power Supply Post Regulation
