NUD4700SNT1G Integrated Circuit Chip LED Protection Devices SCR Electronic Shunt
NUD4700SNT1G Integrated Circuit Chip LED Protection Devices SCR Electronic Shunt
Description
Part Number:
NUD4700SNT1G
Breakdown Voltage::
7.5 V
On-State Voltage::
1.2 V
Rated Repetitive Off-State Voltage VDRM::
10 V
Holding Current Ih Max::
12 MA
On-State RMS Current - It RMS::
376 MA
Highlight:
NUD4700SNT1G LED protection IC
,
SCR electronic shunt chip
,
integrated circuit LED protection device
NUD4700SNT1G Integrated Circuit Chip LED Protection Devices SCR Electronic Shunt
Product Description Of NUD4700SNT1G
NUD4700SNT1G is an electronic shunt which provides a current bypass in the case of a single LED going into open circuit. LEDs are by nature quite fragile when subjected to transients and surge conditions. There are also many cases where high reliability of the LED lighting must be maintained such as headlights, lighthouses, bridges, aircraft, runways and so forth. In these cases the low cost addition of the NUD4700SNT1G will provide full assurance that an entire string of LEDs will not extinguish should one LED fail. NUD4700SNT1G is also applicable to other loads where circuit continuity is required.This device is designed to be used with 1W LEDs (nominally 350mA @ 3V).
Specifications Of NUD4700SNT1G
7.5 V
1.2 V
10 V
Holding Current Ih Max:
12 mA
Maximum Operating Temperature:
+ 150 C
Minimum Operating Temperature:
- 40 C
Off-State Leakage Current @ VDRM IDRM:
1.3 A
On-State RMS Current - It RMS:
376 mA
Unit Weight:
2 g
Features Of NUD4700SNT1G
A Simple Two Terminal Device
Automatically Resets Itself if the LED Heals Itself or is Replaced
ON-State Voltage Typically 1 V
OFF-State Current less than 250 µA
This is a Pb-Free Device
Applications Of NUD4700SNT1G
LEDs where Preventive Maintenance is Non Practical
LEDs with High Reliability Requirements
Crowbar Protection for Open Circuit Conditions
Overvoltage Protection for Sensitive Circuits
