Product Description Of SI52147-A01AGMR
SI52147-A01AGMR is a high-performance, PCIe clock generator that can source nine PCIe clocks from a 25 MHz crystal or clock input. The clock outputs are compliant to PCIe Gen 1, Gen 2, Gen 3, Gen 3 SRNS and Gen 4 common clock specifications. The device has six hardware output enable control pins for enabling and disabling differential outputs. A spread spectrum control pin for EMI reduction is also available.
Specifications Of SI52147-A01AGMR
9 Output
100 MHz
25 MHz
53 %
1 ps
3.465 V
3.135 V
85 mA
- 40 C
+ 85 C
Operating Supply Voltage:
3.3 V
Unit Weight:
150.500 mg
Features Of SI52147-A01AGMR
PCI-Express Gen 1, Gen 2, Gen 3, and Gen 4 common clock compliant
Gen 3 SRNS Compliant
Supports Serial-ATA (SATA) at 100 MHz
Low power push-pull HCSL compatible differential outputs
No termination resistors required
Output enable pins for all clocks
Spread enable pin
25 MHz crystal input or clock input
Up to nine PCI-Express clock outputs
I2C support with readback capabilities
Triangular spread spectrum profile for maximum electromagnetic interference (EMI) reduction
Industrial temperature:–40 to 85 ℃
3.3 V power supply
48-pin QFN package
Applications Of SI52147-A01AGMR
Network attached storage
Multi-function printer
Wireless access point
Servers
