SKY85331-11 Wireless Communication Module 2 GHz WLAN Front-End Module LGA-24

SKY85331-11 Wireless Communication Module 2 GHz WLAN Front-End Module LGA-24

Product Description Of SKY85331-11
SKY85331-11 is a highly integrated, 2 GHz front-end module (FEM) incorporating a 2 GHz single-pole, double-throw (SPDT) transmit/receive (T/R) switch, a 2 GHz low-noise amplifier (LNA) with bypass, and a 2 GHz power amplifier (PA) intended for high-power 802.11ac applications and systems.

Specifications Of SKY85331-11

Features Of SKY85331-11
Integrated high-performance 2 GHz PA, LNA with bypass, and T/R switch
Fully matched input and output
Integrated logarithmic power detector
Transmit gain: 33 dB
Receive gain: 15 dB
Output power: +22 dBm @ 1.8% EVM, HT40, MCS9, 5 V
Output power: +26 dBm @ 3% EVM, HT40, MCS7, 5 V
Small (24-pin, 3 x 5 mm) laminate package

Applications Of SKY85331-11
802.11ac networking and personal computing systems
PC cards, PCMCIA cards, mini-cards, and half mini-cards
WLAN-enabled wireless video systems
