USB2514BT-I/M2 Integrated Circuit Chip 4-Port USB 2.0 Hi-Speed Hub Controller SQFN36

USB2514BT-I/M2 Integrated Circuit Chip 4-Port USB 2.0 Hi-Speed Hub Controller SQFN36​

Product Description Of USB2514BT-I/M2

USB2514BT-I/M2 is a versatile, cost-effective, and power-efficient USB 2.0 hub controllers. USB2514BT-I/M2 uses MultiTRAK™ technology to provide industry-leading data throughput in mixed-speed USB environments. It is a USB port expansion solution suitable for applications that require ultra-low power consumption and small size without compromising performance. USB2514BT-I/M2 supports an extended operating temperature range of 0°C to 85°C.

Specification Of USB2514BT-I/M2

Features Of USB2514BT-I/M2

High performance, ultra low-power, small footprint hub controller IC with 4 downstream ports
Fully compliant with the USB 2.0 specification
Enhanced OEM configuration options available through either a single serial I²C® EEPROM, or SMBus slave port
MultiTRAK - High-performance multiple transaction translator which provides one transaction translator per port
Supports a single external 3.3 V supply source; internal regulators provide 1.2 V internal core voltage
Onboard 24 MHz crystal driver, ceramic resonator, or external 24/48 MHz clock input
Customizable vendor ID, product ID, and device ID
4 kilovolts of HBM JESD22-A114F ESD protection (powered and unpowered)
Supports self- or bus-powered operation
Support the USB Battery Charging specification Rev. 1.1 for Charging Downstream Ports (CDP)
36-pin QFN (6x6 mm) RoHS compliant package
Support the extended commercial temperature range of 0°C to +85°C

Applications Of USB2514BT-I/M2

LCD monitors and TVs
Multi-function USB peripherals
PC motherboards
Set-top boxes, DVD players, DVR/PVR
Printers and scanners
PC media drive bay
Portable hub boxes
Mobile PC docking
Embedded systems
