STGB10NB37LZT4 Integrated Circuit Chip 10A 410V Internally Clamped IGBT Transistors TO-263-3

Large Image : STGB10NB37LZT4 Integrated Circuit Chip 10A 410V Internally Clamped IGBT Transistors TO-263-3

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	STGB10NB37LZT4

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TO-263-3
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

STGB10NB37LZT4 Integrated Circuit Chip 10A 410V Internally Clamped IGBT Transistors TO-263-3

Description

Part Number:	STGB10NB37LZT4	Voltage - Collector Emitter Breakdown (Max):	440 V
Current - Collector (Ic) (Max):	20 A	Current - Collector Pulsed (Icm):	40 A
Vce(on) (Max) @ Vge, Ic:	1.8V @ 4.5V, 10A	Power - Max:	125 W

STGB10NB37LZT4 Integrated Circuit Chip 10A 410V Internally Clamped IGBT Transistors TO-263-3

Product Description Of STGB10NB37LZT4
STGB10NB37LZT4 IGBT utilizes the advanced PowerMESH™ process resulting in an excellent trade-off between switching performance and low on-state behavior. The built in collector-gate Zener exhibits a very precise active clamping while the gateemitter Zener supplies an ESD protection.

Specifications Of STGB10NB37LZT4

Voltage - Collector Emitter Breakdown (Max)	440 V
Current - Collector (Ic) (Max)	20 A
Current - Collector Pulsed (Icm)	40 A
Vce(on) (Max) @ Vge, Ic	1.8V @ 4.5V, 10A
Power - Max	125 W
Switching Energy	2.4mJ (on), 5mJ (off)
Input Type	Standard
Gate Charge	28 nC
Td (on/off) @ 25°C	1.3µs/8µs
Test Condition	328V, 10A, 1kOhm, 5V
Operating Temperature	-65°C ~ 175°C (TJ)

Features Of STGB10NB37LZT4
Low threshold voltage
Low on-voltage drop
Low gate charge
High current capability
High voltage clamping feature

Applications Of STGB10NB37LZT4
Automotive ignition
