TPS5402DR Integrated Circuit Chip 1.7A Non-Synchronous Step-Down Regulator SOIC8

Large Image : TPS5402DR Integrated Circuit Chip 1.7A Non-Synchronous Step-Down Regulator SOIC8

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	TPS5402DR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	SOIC-8
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

TPS5402DR Integrated Circuit Chip 1.7A Non-Synchronous Step-Down Regulator SOIC8

Description

Part Number:	TPS5402DR	Output Voltage:	800 MV
Output Current:	1.7 A	Quiescent Current:	100 UA
Switching Frequency:	50 KHz To 1.1 MHz	Input Voltage:	3.5 V To 28 V
Highlight:	TPS5402DR step-down regulator IC , 1.7A non-synchronous buck converter , SOIC8 voltage regulator chip

TPS5402DR Integrated Circuit Chip 1.7A Non-Synchronous Step-Down Regulator SOIC8

Product Attributes

Attribute	Value
Part Number	TPS5402DR
Output Voltage	800 mV
Output Current	1.7 A
Quiescent Current	100 uA
Switching Frequency	50 kHz to 1.1 MHz
Input Voltage	3.5 V to 28 V

Product Description

TPS5402DR is a monolithic non-synchronous buck regulator with wide operating input voltage range from 3.5 V to 28 V. Current mode control with internal slope compensation is implemented to reduce component count.

TPS5402DR also features a light load pulse skipping mode, which allows for a power loss reduction from the input power supply to the system at light loading.

Specifications

Function	Step-Down
Output Configuration	Positive
Topology	Buck
Output Type	Adjustable
Number of Outputs	1
Voltage - Input (Min)	3.5V
Voltage - Input (Max)	28V
Voltage - Output (Min/Fixed)	0.8V
Voltage - Output (Max)	26.04V
Current - Output	1.7A
Frequency - Switching	50kHz ~ 1.1MHz
Synchronous Rectifier	No
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOIC

Features

3.5V to 28V Wide Input Voltage Range
Up to 1.7A Maximum Continuous Output Loading Current
Pulse Skipping Mode to Achieve High Light Load Efficiency
High Light Load Efficiency
Frequency Spread Spectrum to Reduce EMI
Adjustable 50-kHz to 1.1-MHz Switching Frequency Set by an External Resistor (Leave pin ROSC floating. Set frequency to 120 kHz and ground connection to 70kHz)
Frequency Spread Spectrum to Ease EMI Issue
Peak Current-Mode Control
Cycle-by-Cycle Over Current Protection
External Soft Start
Available in SOIC8 Package

Applications

5V, 9V, 12V and 24V Distributed Power Systems

Consumer Applications Such as Home Appliances, Set-Top Boxes, CPE Equipment, LCD Displays, Peripherals, and Battery Chargers

Industrial and Car Entertainment Power Supplies
