170335-3607 Connectors Impact 85Ω Vertical Header Backplane Connectors

170335-3607 Connectors Impact 85Ω Vertical Header Backplane Connectors
170335-3607 Connectors Impact 85Ω Vertical Header Backplane Connectors

Large Image :  170335-3607 Connectors Impact 85Ω Vertical Header Backplane Connectors

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: 170335-3607
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 192POS
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day

170335-3607 Connectors Impact 85Ω Vertical Header Backplane Connectors

Description
Part Number: 170335-3607 Number Of Positions: 192
Number Of Rows: 12 Number Of Columns: 16
Contact Finish Thickness: 30.0µin (0.76µm) Operating Temperature: -55°C ~ 85°C
Highlight:

85Ω vertical header connectors

,

backplane connectors with impact resistance

,

vertical header backplane connectors

170335-3607 Connectors Impact 85Ω Vertical Header Backplane Connectors
Product Attributes
Attribute Value
Part Number 170335-3607
Number of Positions 192
Number of Rows 12
Number of Columns 16
Contact Finish Thickness 30.0µin (0.76µm)
Operating Temperature -55°C ~ 85°C
Product Description

170335-3607 Connectors Impact 85 Ω Vertical Header Backplane Connectors

Product Description Of 170335-3607
170335-3607 is Impact 85 Ohm Plus 4 Pair Vertical Header Backplane Connectors, Left Guide, Open End Walls, 16 Columns, 192 Circuits, Pin Length 4.90mm, Plated Through Hole Dimension 0.39mm, Lead-Free.

Specifications
Product: Headers
Number of Positions: 192 Position
Number of Rows: 12 Row
Pitch: 1.35 mm, 1.9 mm
Contact Plating: Gold
Current Rating: 750 mA
Housing Colour: Gray
Housing Material: Thermoplastic (TP)
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
Mounting Angle: Vertical
Product Type: High Speed / Modular Connectors
Voltage Rating: 30 V
Unit Weight: 8.478 g
