IXFP14N85XM Integrated Circuit Chip N-Channel Enhancement X-Class HiPerFET™ Power MOSFET Transistors

Large Image : IXFP14N85XM Integrated Circuit Chip N-Channel Enhancement X-Class HiPerFET™ Power MOSFET Transistors

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	IXFP14N85XM

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TO-220-3
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10000 Pieces per Day

Contact Now

IXFP14N85XM Integrated Circuit Chip N-Channel Enhancement X-Class HiPerFET™ Power MOSFET Transistors

Description

Part Number:	IXFP14N85XM	Vds - Drain-Source Breakdown Voltage::	850 V
Id - Continuous Drain Current::	14 A	Rds On - Drain-Source Resistance::	550 MOhms
Vgs - Gate-Source Voltage::	- 30 V, + 30 V	Vgs Th - Gate-Source Threshold Voltage::	3.5 V
Highlight:	N-Channel Power MOSFET transistor , X-Class HiPerFET integrated circuit , Enhancement mode MOSFET chip

IXFP14N85XM Integrated Circuit Chip N-Channel Enhancement X-Class HiPerFET™ Power MOSFET Transistors

Product Attributes

Attribute	Value
Part Number	IXFP14N85XM
Vds - Drain-Source Breakdown Voltage	850 V
Id - Continuous Drain Current	14 A
Rds On - Drain-Source Resistance	550 mOhms
Vgs - Gate-Source Voltage	- 30 V, + 30 V
Vgs th - Gate-Source Threshold Voltage	3.5 V

Product Description

IXFP14N85XM is N-Channel Enhancement X-Class HiPerFET™ Power MOSFET Transistors.

Specifications

Parameter	Value
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	850 V
Current - Continuous Drain (Id) @ 25°C	14A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	550mOhm @ 7A, 10V
Vgs(th) (Max) @ Id	5.5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	30 nC @ 10 V
Vgs (Max)	±30V
Input Capacitance (Ciss) (Max) @ Vds	1043 pF @ 25 V
Power Dissipation (Max)	38W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)

Features

International Standard Package
Plastic Overmolded Tab
Low RDS(ON) and QG
Avalanche Rated
2500V~ Electrical Isolation
Low Package Inductance

Advantages

High Power Density
Easy to Mount
Space Savings

Applications

Switch-Mode and Resonant-Mode Power Supplies
DC-DC Converters
PFC Circuits
AC and DC Motor Drives
Robotics and Servo Controls
