MPM38222GR Integrated Circuit Chip Dual 2A Synchronous Step-Down Converter With Integrated Inductors

MPM38222GR Integrated Circuit Chip Dual 2A Synchronous Step-Down Converter With Integrated Inductors
MPM38222GR Integrated Circuit Chip Dual 2A Synchronous Step-Down Converter With Integrated Inductors

Large Image :  MPM38222GR Integrated Circuit Chip Dual 2A Synchronous Step-Down Converter With Integrated Inductors

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MPM38222GR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 14-QFN
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

MPM38222GR Integrated Circuit Chip Dual 2A Synchronous Step-Down Converter With Integrated Inductors

Description
Part Number: MPM38222GR Input Voltage - Max:: 6 V
Output Voltage:: 608 MV To 6 V Output Current:: 2 A
Switching Frequency:: 1 MHz Input Voltage - Min:: 2.7 V
Highlight:

dual 2A synchronous step-down converter

,

integrated circuit chip with inductors

,

MPM38222GR step-down converter chip

MPM38222GR Integrated Circuit Chip Dual 2A Synchronous Step-Down Converter With Integrated Inductors
Product Attributes
Attribute Value
Part Number MPM38222GR
Input Voltage - Max 6 V
Output Voltage 608 mV to 6 V
Output Current 2 A
Switching Frequency 1 MHz
Input Voltage - Min 2.7 V
Product Description

MPM38222GR is a dual-channel DC/DC module. The module includes a monolithic, step-down, switch-mode converter with built-in, internal power MOSFETs and inductors. The MPM38222GR is designed to simplify power system design and provide ease of use.

Specifications
Specification Value
Number of Outputs 2
Voltage - Input (Min) 2.7V
Voltage - Input (Max) 6V
Voltage - Output 1 1.8V
Voltage - Output 2 1.2V
Current - Output (Max) 2A, 2A
Applications ITE (Commercial)
Operating Temperature -40°C ~ 125°C (TJ)
Efficiency 93%
Mounting Type Surface Mount
Package / Case 14-PowerLFQFN Module
Size / Dimension 0.16" L x 0.16" W x 0.06" H (4.1mm x 4.1mm x 1.5mm)
Features
  • Dual 2A Output Current
  • >93% Peak Efficiency
  • >80% Light-Load Efficiency
  • Ultra-Low IQ: 45μA
  • 80mΩ and 35mΩ Internal Power MOSFET
  • Wide 2.7V to 6V Operating Input Range
  • Default 1MHz Switching Frequency
  • 180° Phase-Shifted Operation
  • 100% Duty Cycle Operation
  • Cycle-by-Cycle Over-Current Protection(OCP)
  • Short-Circuit Protection (SCP) with Hiccup Mode
  • Thermal Shutdown
  • Available in a Small QFN-14 (4mmx4mmx1.6mm) Package
Applications
  • Optical Modules
  • Industrial Products
  • IoT Devices
  • LDO Replacements
  • Medical Devices
