MP2762AGV-0201-Z Integrated Circuit Chip 6A Dual-Phase NVDC Buck-Boost Charger With Integrated FETs And OTG

MP2762AGV-0201-Z Integrated Circuit Chip 6A Dual-Phase NVDC Buck-Boost Charger With Integrated FETs And OTG
MP2762AGV-0201-Z Integrated Circuit Chip 6A Dual-Phase NVDC Buck-Boost Charger With Integrated FETs And OTG

Large Image :  MP2762AGV-0201-Z Integrated Circuit Chip 6A Dual-Phase NVDC Buck-Boost Charger With Integrated FETs And OTG

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MP2762AGV-0201-Z
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: QFN-30
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

MP2762AGV-0201-Z Integrated Circuit Chip 6A Dual-Phase NVDC Buck-Boost Charger With Integrated FETs And OTG

Description
Part Number: MP2762AGV-0201-Z Battery Type:: Multiple Cell
Output Voltage:: 9 V Output Current:: 6 A
Operating Supply Voltage:: 4 V To 21 V Operating Supply Current:: 6 A
Highlight:

6A dual-phase NVDC buck-boost charger

,

integrated circuit chip with FETs

,

buck-boost charger with OTG function

MP2762AGV-0201-Z Integrated Circuit Chip 6A Dual-Phase NVDC Buck-Boost Charger With Integrated FETs And OTG
Product Attributes
Attribute Value
Part Number MP2762AGV-0201-Z
Battery Type Multiple Cell
Output Voltage 9 V
Output Current 6 A
Operating Supply Voltage 4 V to 21 V
Operating Supply Current 6 A
Product Description

MP2762AGV-0201-Z is a highly integrated buck or boost charger IC with narrow voltage DC (NVDC) power path management and USB On the-Go (OTG) for battery packs with two cells in series. All power MOSFETs are integrated to provide a compact system solution size.

Specifications
Parameter Value
Number of Cells 2
Current - Charging Constant - Programmable
Programmable Features Current, Timer, Voltage
Fault Protection Over Temperature, Over-Under Voltage
Charge Current - Max 6A
Battery Pack Voltage 8.4V
Voltage - Supply (Max) 21V
Interface USB
Operating Temperature -40°C ~ 125°C (TJ)
Features
  • Buck or Boost Charger for Battery Packs with Two Cells in Series
  • NVDC Power Management
  • All MOSFETs Integrated
  • 4V to 21V Operation Voltage Range
  • Up to 28V (20ns) Sustainable Input Voltage
  • Dual-Phase Interleaving in Buck Charging Mode
  • Configurable Input Voltage Limit
  • Up to 6A Configurable Input Current Limit
  • Up to 6A Configurable Charge Current
  • Configurable Battery-Full Voltage Up to 9V
  • System Power Indication via PSYS Pin
  • Input Current and Battery Current Monitoring via IAM and IBM Pins
  • Input Over-Voltage Protection (OVP)
  • Battery Temperature Protection
  • Battery Over-Voltage Protection (OVP)
  • System Over-Voltage Protection (OVP)
  • Configurable Safety Charge Timer
  • Thermal Regulation and Thermal Shutdown
  • 600kHz, 800kHz, and 1MHz Configurable Switching Frequency for Each Phase
  • Input Power Source Status Indication Pin
  • I2C Interface to Support Flexible Parameter Control
  • Comprehensive Fault and Status Reporting in Register
  • Up to 5V/3A USB On-the-Go (OTG)
  • Configurable Output Current Limit OTG Mode
  • Short-Circuit Protection (SCP) in OTG Mode
  • Available in a QFN-30 (4mmx5mm) Package
Applications
  • Smartphones with Two Cells in Series
  • Bluetooth Speakers
  • Portable Gimbals
