AP6212 BT IC Highly Integrated Single Band Wi-Fi 11b/g/n And BT 5.4 Module QFN-44
Product Attributes
| Attribute |
Value |
| Part Number |
AP6212 |
| Operating temperature |
-30°C to 85°C |
| Frequency Range |
2.4GHz ~ 2.497 GHz |
| Number of Channels |
79 |
| Channel step |
50 KHz |
| Package |
QFN-44 |
Product Description
AP6212 is a module with comprehensive Wi-Fi and BT functionality. This highly integrated module enables a wide range of applications, including web browsing, VoIP, and Bluetooth headsets.
In addition, it offers unlimited roaming capabilities and advanced security, and can interact with 802.11b/g/n access points from different vendors in a wireless local area network. The wireless module complies with the IEEE 802.11 b/g/n standards, achieving a maximum speed of 72.2 Mbps in single-antenna transmission under the 802.11n specification, 54 Mbps as specified by IEEE 802.11g, or 11 Mbps as specified by IEEE 802.11b for connecting to a wireless local area network.
This integrated module provides an SDIO interface for Wi-Fi and a UART/I2S/PCM interface for BT. This compact module combines Wi-Fi and BT technology, offering a comprehensive solution specifically designed for portable devices.
Features
- 802.11b/g/n single-band radio
- Bluetooth V4.0(HS) with integrated Class 1.5 PA and Low Energy (BLE) support
- Concurrent Bluetooth, FM (RX) RDS/RBDS, and WLAN operation
- Simultaneous BT/WLAN receive with single antenna
- WLAN host interface options: SDIO v2.0 -- up to 50 MHz clock rate
- BT host digital interface: UART (up to 4 Mbps)
- FM multiple audio routing options: I2S, PCM, eSCO, A2DP
- IEEE Co-existence technologies are integrated die solution
- ECI -- enhanced coexistence support, ability to coordinate BT SCO transmissions around WLAN receives
