HCNR201-500E Integrated Circuit Chip 5000Vrms High-Linearity Analog Optocouplers DIP8

HCNR201-500E Integrated Circuit Chip 5000Vrms High-Linearity Analog Optocouplers DIP8
HCNR201-500E Integrated Circuit Chip 5000Vrms High-Linearity Analog Optocouplers DIP8

Large Image :  HCNR201-500E Integrated Circuit Chip 5000Vrms High-Linearity Analog Optocouplers DIP8

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: HCNR201-500E
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: DIP-8
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

HCNR201-500E Integrated Circuit Chip 5000Vrms High-Linearity Analog Optocouplers DIP8

Description
Part Number: HCNR201-500E Current Transfer Ratio: 0.36 % To 0.72 %
Number Of Channels: 1 Channel If - Forward Current: 20 MA
Pd - Power Dissipation: 60 MW Isolation Voltage: 5000 Vrms
Highlight:

HCNR201-500E analog optocoupler DIP8

,

5000Vrms high-linearity optocoupler chip

,

integrated circuit optocoupler with warranty

HCNR201-500E Integrated Circuit Chip 5000Vrms High-Linearity Analog Optocouplers DIP8
Product Attributes
Attribute Value
Part Number HCNR201-500E
Current Transfer Ratio 0.36 % to 0.72 %
Number of Channels 1 Channel
If - Forward Current 20 mA
Pd - Power Dissipation 60 mW
Isolation Voltage 5000 Vrms
Product Description

HCNR201-500E is high-linearity analog optocoupler consists of a high-performance AlGaAs LED that illuminates two closely matched photodiodes. The input photodiode monitors, and therefore stabilizes, the light output of the LED.

Specification
Parameter Value
Number of Channels 1
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Min) 0.36% @ 10mA
Current Transfer Ratio (Max) 0.72% @ 10mA
Input Type DC
Output Type Photovoltaic, Linearized
Voltage - Forward (Vf) (Typ) 1.6V
Current - DC Forward (If) (Max) 25 mA
Operating Temperature -55°C ~ 100°C
Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing
Supplier Device Package 8-DIP Gull Wing
Features
  • Low nonlinearity: 0.01%
  • K3 (IPD2/IPD1) transfer gain: ±5%
  • Low gain temperature coefficient: 65 ppm/°C
  • Wide bandwidth - DC to >1 MHz
  • Surface mount option available
  • 8-pin DIP package - 0.400-in. spacing
  • Allows flexible circuit design
Applications
  • Low cost analog isolation
  • Telecom: Modem, PBX
  • Industrial process control:
    • Transducer isolator
    • Isolator for thermocouples 4 mA to 20 mA loop isolation
  • SMPS feedback loop, SMPS feedforward
  • Monitor motor supply voltage
  • Medical
