XC7Z045-2FFG676I Field Programmable Gate Array Dual-Core ARM Cortex-A9 MP Zynq®-7000 System On Chip

XC7Z045-2FFG676I is a Dual-Core ARM Cortex-A9 MP Zynq®-7000 System On Chip. The Zynq®-7000 family is based on the SoC architecture. These products integrate a feature-rich dual-core or single-core ARM®Cortex™-A9 based processing system (PS) and 28 nm Xilinx programmable logic (PL) in a single device. The ARM Cortex-A9 CPUs are the heart of the PS and also include on-chip memory, external memory interfaces, and a rich set of peripheral connectivity interfaces.

• ARM Cortex-A9 Based Application Processor Unit (APU)
• 2.5 DMIPS/MHz per CPU
• CPU frequency: Up to 1 GHz
• Coherent multiprocessor support
• ARMv7-A architecture
• TrustZone® security
• Thumb®-2 instruction set
• Jazelle® RCT execution Environment Architecture
• NEON™ media-processing engine
• Single and double precision Vector Floating Point Unit (VFPU)
• CoreSight™ and Program Trace Macrocell (PTM)
• Timer and Interrupts
• Three watchdog timers
• One global timer
• Two triple-timer counters
• Caches
• 32 KB Level 1 4-way set-associative instruction and data caches (independent for each CPU)
• 512 KB 8-way set-associative Level 2 cache (shared between the CPUs)
• Byte-parity support
• On-Chip Memory
• On-chip boot ROM
• 256 KB on-chip RAM (OCM)
• Byte-parity support
• External Memory Interfaces
• Multiprotocol dynamic memory controller
• 16-bit or 32-bit interfaces to DDR3, DDR3L, DDR2, or LPDDR2 memories
• ECC support in 16-bit mode
• 1GB of address space using single rank of 8-, 16-, or 32-bit-wide memories
• Static memory interfaces
• 8-bit SRAM data bus with up to 64 MB support
• Parallel NOR flash support
• ONFI1.0 NAND flash support (1-bit ECC)
• 1-bit SPI, 2-bit SPI, 4-bit SPI (quad-SPI), or two quad-SPI (8-bit) serial NOR flash
• 8-Channel DMA Controller
• Memory-to-memory, memory-to-peripheral, peripheral-to-memory, and scatter-gather transaction support
