A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC

A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC
A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC

Large Image :  A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: A4950ELJTR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOIC-8
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC

Description
Part Number: A4950ELJTR Output Current:: 3.5 A
Operating Supply Current:: 10 MA Minimum Operating Temperature:: - 40 C
Maximum Operating Temperature:: + 85 C Load Voltage Rating:: 8 V To 40 V
Highlight:

A4950ELJTR motor driver IC

,

DMOS PWM motor driver

,

8-SOIC full-bridge driver

A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC
Product Attributes
Attribute Value
Part Number A4950ELJTR
Output Current 3.5 A
Operating Supply Current 10 mA
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
Load Voltage Rating 8 V to 40 V
Product Description

A4950ELJTR Integrated Circuit Chip Full-Bridge DMOS PWM Motor Driver 8-SOIC

Designed for pulse width modulated (PWM) control of DC motors, the A4950ELJTR is capable of peak output currents to ±3.5A and operating voltages to 40 V. Input terminals are provided for use in controlling the speed and direction of a DC motor with externally applied PWM control signals. Internal synchronous rectification control circuitry is provided to lower power dissipation during PWM operation. Internal circuit protection includes overcurrent protection, motor lead short to ground or supply, thermal shutdown with hysteresis, undervoltage monitoring of VBB, and crossovercurrent protection.

Specifications
Motor Type AC, DC | Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface Analog
Technology DMOS
Step Resolution -
Applications General Purpose
Current - Output 3.5A
Voltage - Supply 8V ~ 40V
Voltage - Load 8V ~ 40V
Operating Temperature -40°C ~ 150°C (TJ)
Features
  • Low RDS(on) outputs
  • Overcurrent protection (OCP)
  • Motor short protection
  • Motor lead short to ground protection
  • Motor lead short to battery protection
  • Low Power Standby mode
  • Adjustable PWM current limit
  • Synchronous rectification
  • Internal undervoltage lockout (UVLO)
  • Crossover-current protection
  • Commercial temperature grade (A4950E: -40°C to 85°C)
