TLE4998C8 Sensor IC XENSIV™ Programmable Linear Hall Sensor TDSO-8 Package

TLE4998C8 Linear sensor for precise angle & position detection. Digital SPC signal based on SENT protocol. "Range selection" & "ID selection" modes available. Enables dynamic range switching & bus system with up to 4 ICs on a single output line.

• Linear Hall Sensors: Enhanced Interface
• 20-bit Digital Signal Processing (DSP)
• Digital temperature & stress compensation
• 16-bit overall resolution
• Automotive temperature range -40°C to 125°C
• Drift of output signal over temperature & lifetime
• Magnetic range, sensitivity (gain), offset
• Bandwidth
• Clamping levels
• Customer temp compensation coefficients
• Re-programmable until memory lock
• Supply voltage 4.5-5.5 V (4.1-16 V extended range)

• Electric power steering (EPS)
• Robust replacement of potentiometers: No mechanical abrasion, resistant to humidity, temperature, pollution and vibration
• Linear and angular position sensing in automotive and industrial applications with highest accuracy requirements
• Suited for safety applications such as pedal position, throttle position and steering torque sensing

Yes, all products are original, new original import is our purpose.

We are ISO 9001:2015 Certified Company and member of ERAI.

Yes, we support sample order and small order. Sample cost is different according to your order or project.

We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
