OPA2992IDSGR Integrated Circuit Chip Low Noise Operational Amplifiers 40V Op Amp Chip
Product Attributes
| Attribute |
Value |
| Part Number |
OPA2992IDSGR |
| Number of Channels |
1 Channel |
| GBP - Gain Bandwidth Product |
10.6 MHz |
| SR - Slew Rate |
32 V/us |
| Vos - Input Offset Voltage |
210 uV |
| Ib - Input Bias Current |
10 pA |
Product Description
OPA2992IDSGR is 40V, Rail-to-Rail Input/Output, Low Offset Voltage, Low Noise Operational Amplifiers. OPA2992IDSGR offer excellent DC precision and AC performance, including rail-to-rail input/output, low offset (±210µV, typical), low offset drift (±0.25µV/°C, typical) and low noise (7nV/√Hz at 1kHz, 4.4nV √Hz at 10kHz).
Features such as differential and common-mode input voltage ranges to the supply rails, high short-circuit current (±65mA), and high slew rate (32V/µs) make the OPA2992IDSGR a flexible, robust, and high-performance op amp for high-voltage industrial applications.
Specifications
| Amplifier Type |
Standard (General Purpose) |
| Number of Circuits |
2 |
| Output Type |
Rail-to-Rail |
| Slew Rate |
32V/µs |
| Gain Bandwidth Product |
10.6 MHz |
| Current - Input Bias |
10 pA |
| Voltage - Input Offset |
210 µV |
| Current - Supply |
2.4mA (x2 Channels) |
| Current - Output / Channel |
65 mA |
| Operating Temperature |
-40°C ~ 125°C (TA) |
| Mounting Type |
Surface Mount |
| Package / Case |
8-WFDFN Exposed Pad |
| Supplier Device Package |
8-WSON (2x2) |
Features
- Low offset voltage: ±210µV
- Low offset voltage drift: ±0.25µV/°C
- Low noise: 7nV/√Hz at 1kHz, 4.4nV/√Hz broadband
- High common-mode rejection: 115dB
- Low bias current: ±10pA
- Rail-to-rail input and output
- Wide bandwidth: 10.6MHz GBW, unity-gain stable
- High slew rate: 32V/µs
- Low quiescent current: 2.4mA per amplifier
- Wide supply: ±1.35V to ±20V, 2.7V to 40V
- Robust EMIRR performance
- MUX-friendly/comparator inputs
- Amplifier operates with differential inputs up to supply rail
- Amplifier can be used in open-loop or as comparator
OPA2992IDSGR in Current-Sensing Applications
