TJA1051T Integrated Circuit Chip 5Mbps 4.5V To 5.5V High-Speed CAN Transceiver

TJA1051T Integrated Circuit Chip 5Mbps 4.5V To 5.5V High-Speed CAN Transceiver

Product Description
TJA1051T is a high-speed CAN transceiver that provides an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. The transceiver is designed for high-speed CAN applications in the automotive industry, providing differential transmit and receive capability to (a microcontroller with) a CAN protocol controller.

Specifications

Features
ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 compliant
Timing guaranteed for data rates up to 5 Mbit/s in the CAN FD fast phase
Suitable for 12 V and 24 V systems
Low ElectroMagnetic Emission (EME) and high ElectroMagnetic Immunity (EMI)
VIO input on TJA1051T/3 and TJA1051TK/3 allows for direct interfacing with 3 V to 5 V microcontrollers (available in SO8 and very small HVSON8 packages respectively)
EN input on TJA1051T/E allows the microcontroller to switch the transceiver to a very low-current Off mode
Available in SO8 package or leadless HVSON8 package (3.0 mm  3.0 mm) with improved Automated Optical Inspection (AOI) capability
Dark green product (halogen free and Restriction of Hazardous Substances (RoHS) compliant)
AEC-Q100 qualified
Functional behavior predictable under all supply conditions
Transceiver disengages from the bus when not powered up (zero load)
High ElectroStatic Discharge (ESD) handling capability on the bus pins
Bus pins protected against transients in automotive environments
Transmit Data (TXD) dominant time-out function
Undervoltage detection on pins VCC and VIO
Thermally protected
