IPD60R950C6 Integrated Circuit Chip CoolMOS C6 Power Transistor 600V MOSFET Transistor

IPD60R950C6 Integrated Circuit Chip CoolMOS C6 Power Transistor 600V MOSFET Transistor
IPD60R950C6 Integrated Circuit Chip CoolMOS C6 Power Transistor 600V MOSFET Transistor

Large Image :  IPD60R950C6 Integrated Circuit Chip CoolMOS C6 Power Transistor 600V MOSFET Transistor

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IPD60R950C6
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TO-252-3
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

IPD60R950C6 Integrated Circuit Chip CoolMOS C6 Power Transistor 600V MOSFET Transistor

Description
Part Number: IPD60R950C6 Vds - Drain-Source Breakdown Voltage: 600 V
Id - Continuous Drain Current: 4.4 A Rds On - Drain-Source Resistance: 860 MOhms
Qg - Gate Charge: 13 NC Pd - Power Dissipation: 37 W

IPD60R950C6 Integrated Circuit Chip CoolMOS C6 Power Transistor 600V MOSFET Transistor



Product Overviews

IPD60R950C6 is 600V, CoolMOS C6 Power Transistor. IPD60R950C6 provide all benefits of a fast switching SJ MOSFET while not sacrificing ease of use. Extremely low switching and conduction losses make switching applications even more efficient, more compact, lighter, and cooler.

Specification

Series
CoolMOS™ C6
FET Type
N-Channel
Technology
MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)
600 V
Current - Continuous Drain (Id) @ 25°C
4.4A (Tc)
Drive Voltage (Max Rds On, Min Rds On)
10V
Rds On (Max) @ Id, Vgs
950mOhm @ 1.5A, 10V
Vgs(th) (Max) @ Id
3.5V @ 130µA
Gate Charge (Qg) (Max) @ Vgs
13 nC @ 10 V
Vgs (Max)
±20V
Input Capacitance (Ciss) (Max) @ Vds
280 pF @ 100 V
Power Dissipation (Max)
37W (Tc)
Operating Temperature
-55°C ~ 150°C (TJ)
Mounting Type
Surface Mount
Supplier Device Package
PG-TO252-3
Package / Case
TO-252-3, DPAK (2 Leads + Tab), SC-63


Features

Extremely low losses due to very low FOM Rdson Qg and Eoss
Very high commutation ruggedness
Easy to use/drive
Fully qualified according to JEDEC for Industrial Applications
Pb-free plating, Halogen free mold compound


Applications
PFC stages, hard switching PWM stages and resonant switching PWM stages for e.g. PC Silverbox, Adapter, LCD and PDP TV, Lighting, Server, Telecom and UPS.
