TLD7002-16ES Integrated Circuit Chip 16-Channel LED Driver LITIX Automotive LED Driver

TLD7002-16ES Integrated Circuit Chip 16-Channel LED Driver LITIX Automotive LED Driver​

Product Overviews

TLD7002-16ES is a 16-channel device with protected output stages. It controls LEDs up to 76.5 mA as linear current sink (LCS). Power stages can be parallelized for higher load currents. Each output stage is configured with a 6-bit current value stored in OTP. 16 independent PWM configurations are available. A high-speed interface enables OTP programming, configuration, control, and diagnostics.

Specification

Features

16 channel device optimize to drive LEDs
High regulated O/P current upto 76.5mA
Parallel O/P operation for higher load
Configurations ranging from 5.62to76.5mA
16 independent 14-bit PWM engines
Configurable thermal derating
Two voltage measurements (NTC/PTC)
Integrated HSLI transceiver

Applications
Automotive LED lighting systems
Automotive instrument cluster
LED strips and signage
