CXDQ3BFAM-CJ-A Memory IC Chip 8Gb DDR4 SDRAM Memory FBGA-96 Package

CXDQ3BFAM-CJ-A Memory IC Chip 8Gb DDR4 SDRAM Memory FBGA-96 Package

Product Description
CXDQ3BFAM-CJ-A is 8Gb DDR4 SDRAM Memory.

Features
Power supply : VDD = VDDQ = 1.2V (1.14V to 1.26V); VPP = 2.5V (2.375V to 2.75V)
JEDEC standard package: x16 96-ball FBGA
Array Configuration : 8 banks (x16) 2 groups of 4 banks
8n-bit prefetch architecture
Burst Length (BL) : 8 and 4 with Burst Chop (BC)
Programmable CAS Latency (CL)
Programmable CAS Write Latency (CWL)
Internal generated Vref for data inputs
On-Die Termination (ODT) : support Nominal, Park and Dynamic ODT
Differential clock and data strobe inputs
Interface: 1.2V Pseudo Open Drain (POD) IO
Per DRAM Addressability (PDA)
Data Bus Inversion (DBI)
Data Mask (DM) for write data
Maximum Power Saving Mode (MPSM)
LP ASR(Low Power Auto Self Refresh) mode is supported
Asynchronous reset for power up
Precharge: auto precharge option for each burst access
Operating case temperature : 0°C ≤ TCase ≤ 95°C
Support auto-refresh and self-refresh mode8Gb x16 DDR4 SDRAM
Average Refresh Period: 7.8 μs at 0°C ≤ TCase ≤ 85°C; 3.9 μs at 85°C < TCase ≤ 95°C
Fine granularity refresh 2x, 4x mode for smaller tRFC
Programmable data strobe preambles
Command Address (CA) Parity is supported
Write Cyclic Redundancy Code (CRC) is supported
hPPR and sPPR are supported
Connectivity test mode (TEN) is supported
Gear Down Mode
Output driver calibration through ZQ pin (RZQ: 240ohm ±1%)
JEDEC JESD-79-4 compliant
RoHS compliant
