LTC3789EGN Integrated Circuit Chip High Efficiency Synchronous 4-Switch Buck-Boost Controller
Product Description
LTC3789EGN is a high performance buck-boost switching regulator controller that operates from input voltages above, below or equal to the output voltage. The constant-frequency, current mode architecture allows a phase-lockable frequency of up to 600kHz, while an output current feedback loop provides support for battery charging. With a wide 4V to 38V (40V maximum) input and output range and seamless, low noise transitions between operating regions, the LTC3789EGN is ideal for automotive, telecom and battery-powered systems.
Specifications
|
Output Type
|
|
|
Function
|
|
|
Output Configuration
|
|
|
Topology
|
|
|
Number of Outputs
|
|
|
Output Phases
|
|
|
Voltage - Supply (Vcc/Vdd)
|
|
|
Frequency - Switching
|
|
|
Duty Cycle (Max)
|
|
|
Synchronous Rectifier
|
|
|
Clock Sync
|
|
|
Control Features
|
Current Limit, Enable, Frequency Control, Power Good, Soft Start
|
|
Operating Temperature
|
|
Features
Single Inductor Architecture Allows VIN Above, Below or Equal to the Regulated VOUT
Programmable Input or Output Current
Wide VIN Range: 4V to 38V
1% Output Voltage Accuracy: 0.8V < VOUT < 38V
Synchronous Rectification: Up to 98% Efficiency
Current Mode Control
Phase-Lockable Fixed Frequency: 200kHz to 600kHz
No Reverse Current During Start-Up
Power Good Output Voltage Monitor
Internal 5.5V LDO
Quad N-Channel MOSFET Synchronous Drive
nVOUT Disconnected from VIN During Shutdown
True Soft-Start and VOUT Short Protection, Even in Boost Mode
Applications
Automotive Systems
Distributed DC Power Systems
High Power Battery-Operated Devices
Industrial Control
