MLX90316LDC-BDG-100-RE Sensor IC Triaxis Mainstream Rotary Position Sensor IC SOIC8

MLX90316LDC-BDG-100-RE Sensor IC Triaxis Mainstream Rotary Position Sensor IC SOIC8​

Product Overviews

MLX90316LDC-BDG-100-RE is a Triaxis® rotary position sensor IC providing the angular position of a small dipole magnet rotating above the device surface (end-of-shaft magnet), targeting non-contacting rotary position sensor applications in automotive and industrial systems.

Specification

Features

Absolute rotary position sensor IC
Simple and robust magnetic design
Triaxis® Hall technology
Programmable angular range up to 360 degrees
Selectable output mode: analog (ratiometric), PWM or serial protocol (SPI)
12-bit angular resolution over 360 degrees
10-bit angular thermal accuracy
40-bit ID number
-40°C to 150°C ambient temperature range
Broken-track diagnostic (open-Vdd, open-Vss)
On-chip diagnostics
Single die SOIC-8 package RoHS compliant

Applications

Absolute Rotary Position Sensor
Steering Wheel Position Sensor
Pedal Position Sensor
Motor-shaft Position Sensor
Throttle Position Sensor
Float-Level Sensor
Ride Height Position Sensor
Non-Contacting Potentiometer
