10M16SAE144I7G Field Programmable Gate Array MAX 10 FPGA IC EQFP144 Programmable Logic IC

10M16SAE144I7G Field Programmable Gate Array MAX 10 FPGA IC EQFP144 Programmable Logic IC​

Product Overviews

10M16SAE144I7G is MAX® 10 Field Programmable Gate Array (FPGA) IC. MAX® 10 devices are single-chip, non-volatile low-cost programmable logic devices (PLDs) to integrate the optimal set of system components.

Specification

Features

55 nm TSMC Embedded Flash (Flash + SRAM) process technology
Core architecture
- 4-input look-up table (LUT) and single register logic element (LE)
- LEs arranged in logic array block (LAB)
- Embedded RAM and user flash memory
- Clocks and PLLs
- Embedded multiplier blocks
- General purpose I/Os
Internal memory blocks
- M9K—9 kilobits (Kb) memory blocks
- Cascadable blocks to create RAM, dual port, and FIFO functions
Embedded multiplier blocks
- One 18 × 18 or two 9 × 9 multiplier modes
- Cascadable blocks enabling creation of filters, arithmetic functions, and image processing pipelines
ADC
- 12-bit successive approximation register (SAR) type
- Up to 17 analog inputs
- Cumulative speed up to 1 million samples per second ( MSPS)
- Integrated temperature sensing capability
General-purpose I/Os (GPIOs)
- Multiple I/O standards support
- On-chip termination (OCT)
- Up to 720 megabits per second (Mbps) LVDS receiver and transmitter

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
