STGIPQ3H60T-HZ Automotive IGBT Modules 3A 600V 3‑Phase Inverter Bridge IGBT Module

STGIPQ3H60T-HZ Automotive IGBT Modules 3A 600V 3‑Phase Inverter Bridge IGBT Module

Product Description
STGIPQ3H60T-HZ SLLIMM (small low-loss intelligent molded module) nano provides a compact, high-performance AC motor drive in a simple, rugged design. It is composed of six improved short-circuit rugged trench gate fieldstop IGBTs with freewheeling diodes and three half-bridge HVICs for gate driving, providing low electromagnetic interference (EMI) characteristics with optimized switching speed.

Specifications

Features
IPM 3 A, 600 V, 3-phase IGBT inverter bridge including 3 control ICs for gate driving and freewheeling diodes
3.3 V, 5 V, 15 V TTL/CMOS input comparators with hysteresis and pull-down/ pull-up resistors
Internal bootstrap diode
Optimized for low electromagnetic interference
Undervoltage lockout
VCE(SAT) negative temperature coefficient
Shutdown function
Interlocking function
Op-amp for advanced current sensing
Comparator for fault protection against overcurrent
NTC (UL 1434 CA 2 and 4)
Up to ±2 kV ESD protection (HBM C = 100 pF, R = 1.5 kΩ)
Isolation ratings of 1800 Vrms/min.
UL recognition: UL 1557, file E81734

Applications
3-phase induction motor (ACIM)
Dishwasher
Fans
Kitchen hoods
PMSM / BLDC motor control
Refrigerators and freezers
