BQ7694202PFBR Integrated Circuit Chip Multicell Battery Monitor And Protector TQFP48

BQ7694202PFBR Integrated Circuit Chip Multicell Battery Monitor And Protector TQFP48​

Product Description

BQ7694202PFBR is a highly integrated, high accuracy battery monitor and protector for 3-series to 10-series Li-ion, Li-polymer, and LiFePO ‌‌‍‍‍‍‍‍‍‍‍‍‍‍‍‍‍‍‍‍‍4 battery packs.
BQ7694202PFBR includes a high-accuracy monitoring system, a highly configurable protection subsystem, and support for autonomous or host-controlled cell balancing. Integration includes high-side charge-pump NFET drivers, dual programmable LDOs for external system use, and a host communication peripheral supporting 400-kHz I2C, SPI, and HDQ one-wire standards.

Specification

Features

Battery monitoring capability for 3-series to 10-series cells
Integrated charge pump for high-side NFET protection with optional autonomous recovery
Extensive protection suite including voltage, temperature, current, and internal diagnostics
Two independent ADCs
– Support for simultaneous current and voltage sampling
– High-accuracy coulomb counter with input offset error < 1 µV (typical)
– High-accuracy cell voltage measurement < 10 mV (typical)
Wide-range current applications (±200-mV measurement range across sense resistor)
Integrated secondary chemical fuse drive protection
Autonomous or host-controlled cell balancing
Multiple power modes (typical battery pack operating range conditions)
– NORMAL mode: 286 µA
– Multiple SLEEP mode options: 24 µA to 41 µA
– Multiple DEEPSLEEP mode options: 9 µA to 10 µA
– SHUTDOWN Mode: 1 µA
High-voltage tolerance of 85 V on cell connect and select additional pins
Tolerant of random cell attach sequence on production line
Support for temperature sensing using internal sensor and up to nine external thermistors
Integrated one-time-programmable (OTP) memory programmable by customers on production line
Communication options include 400-kHz I2C, SPI, and HDQ one-wire interface
Dual programmable LDOs for external system usage
48-pin TQFP package (PFB)

Applications

Cordless power tools and garden tools
Vacuum cleaners
E-bike, e-scooter, and LEV
Other industrial battery pack (3-series–10-series)
