LMH6643MAX Integrated Circuit Chip Low Power 130MHz 75mA Rail-To-Rail Output Amplifiers

LMH6643MAX Integrated Circuit Chip Low Power 130MHz 75mA Rail-To-Rail Output Amplifiers

Product Description
LMH6643MAX true single supply voltage feedback amplifiers offer high speed (130 MHz), low distortion (−62 dBc), and exceptionally high output current (approximately 75 mA) at low cost and with reduced power consumption when compared against existing devices with similar performance.

Specifications

Features
−3 dB BW (AV = +1) 130 MHz
Supply Voltage Range 2.7 V to 12.8 V
Slew Rate, (AV = −1) 130V/µs(1)
Supply Current (no load) 2.7 mA/amp
Output Short Circuit Current +115 mA to 145 mA
Linear Output Current ±75 mA
Input Common Mode Volt. 0.5 V Beyond V−, 1 V from V+
Output Voltage Swing 40 mV from Rails
Input Voltage Noise (100 kHz) 17nV/√Hz
Input Current Noise (100 kHz) 0.9pA/√Hz
THD (5 MHz, RL = 2 kΩ, VO = 2 VPP, AV = +2) −62 dBc
Settling Time 68 ns
Fully Characterized for 3 V, 5 V, and ±5 V
Overdrive Recovery 100 ns
Output Short Circuit Protected(2)
No Output Phase Reversal with CMVR Exceeded

Applications
Active Filters
CD/DVD ROM
ADC Buffer Amp
Portable Video
Current Sense Buffer
