TOP266KG Integrated Circuit Chip Integrated Off-Line Switcher For Highly Efficient Power Supplies
Product Description
TOP266KG cost effectively incorporates a 725 V power MOSFET, high-voltage switched current source, multi-mode PWM control, oscillator, thermal shutdown circuit, fault protection and other control circuitry onto a monolithic device.
Specifications
|
Output Isolation
|
|
|
Internal Switch(s)
|
|
|
Voltage - Breakdown
|
|
|
Topology
|
|
|
Duty Cycle
|
|
|
Frequency - Switching
|
|
|
Power (Watts)
|
|
|
Fault Protection
|
Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
|
|
Control Features
|
|
|
Operating Temperature
|
|
Product Highlights
EcoSmart – Energy Efficient
• Ideal for applications from 10 W to 245 W
• Energy efficient over entire load range
• No-load consumption below 100 mW at 265 VAC
• Up to 750 mW standby output power for 1 W input at 230 VAC
High Design Flexibility for Low System Cost
• Multi-mode PWM control maximizes efficiency at all loads
• 132 kHz operation reduces transformer and power supply size
• 66 kHz option for highest efficiency requirements
• Accurate programmable current limit
• Optimized line feed-forward for line ripple rejection
• Frequency jittering reduces EMI filter cost
• Fully integrated soft-start for minimum start-up stress
• 725 V rated MOSFET
• Simplifies meeting design derating requirements
Extensive Protection Features
• Auto-restart limits power delivery to <3% during overload faults
• Output short-circuit protection (SCP)
• Output over-current protection (OCP)
• Output overload protection (OPP)
• Output overvoltage protection (OVP)
• User programmable for hysteretic/latching shutdown
• Simple fast AC reset
• Primary or secondary sensed
• Line undervoltage (UV) detection prevents turn-off glitches
• Line overvoltage (OV) shutdown extends line surge withstand
• Accurate thermal shutdown with large hysteresis (OTP)
Applications
Notebook or laptop adapter
Generic adapter
Printer
LCD monitor
Set-top box
PC or LCD TV standby
Audio amplifier
