NCP1252EDR2G Integrated Circuit Chip Current Mode PWM Controller For Forward And Flyback Applications
Product Description
NCP1252EDR2G controller offers everything needed to build cost effective and reliable ac-dc switching supplies dedicated to ATX power supplies or any forward application. Thanks to the use of an internally fixed timer, NCP1252EDR2G detects an output overload without relying on the auxiliary Vcc. A Brown-Out input offers protection against low input voltages and improves the converter safety. Finally, the SOIC-8 package saves PCB space and represents a solution of choice in cost sensitive project.
Specifications
|
Output Isolation
|
|
|
Internal Switch(s)
|
|
|
Topology
|
|
|
Voltage - Start Up
|
|
|
Voltage - Supply (Vcc/Vdd)
|
|
|
Duty Cycle
|
|
|
Frequency - Switching
|
|
|
Fault Protection
|
|
|
Control Features
|
Frequency Control, Soft Start
|
|
Operating Temperature
|
|
Features
Peak current mode control
Adjustable switching frequency
Latched primary overcurrent protection with 10 ms fixed delay
Adjustable soft start timer
Auto recovery brown out detection
Extended Vcc range up to 28 V with auto recovery UVLO
Internal 160 ns leading edge blanking
Frequency jittering
Adjustable internal ramp compensation
+500 mA / -800 mA Source/Sink current driver capability
Skip cycle operation in light/no load operation
SOIC-8 package
Applications
Power supplies for PC silver boxes
Ac-dc adapter converter
Game Adapter
Flyback and Forward Application
