RTL8211E-VB-CG Ethernet IC Integrated 10/100/1000M Ethernet Transceiver QFN48

RTL8211E-VB-CG Ethernet IC Integrated 10/100/1000M Ethernet Transceiver QFN48​

Product Overviews

RTL8211E-VB-CG is highly integrated Ethernet transceivers that comply with 10Base-T, 100Base-TX, and 1000Base-T IEEE 802.3 standards. RTL8211E-VB-CG provide all the necessary physical layer functions to transmit and receive Ethernet packets over CAT.5 UTP cable.

Features

1000Base-T IEEE 802 .3ab Compliant
100Base-TX IEEE 802.3u Compliant
10Base-T IEEE 802.3 Compliant
Supports IEEE 802.3az-2010 (Energy Efficient Ethernet)
Built-in Wake-on-LAN (WOL)
Supports Interrupt function
Supports Parallel Detection
Crossover Detection & Auto-Correction
Automatic polarity correction
Supports PHYRSTB core power Turn-Off
Baseline W ander Correction
Supports 120m for CAT5 cable in 1000Base-T
Supports 3.3V or 2.5V signaling for RGMII/GMII
Supports 25/50MHz external crystal or OSC
Provides 1 25MHz clock source for MAC
Provides 3 network status LEDs
Supports Link Down power saving
Green Ethernet (1000/100Mbps mode only)
Built-in switching regulator
Packages: 48-pin QFN
0.11μm process with very low power consumption

Applications

DTV (Digital TV)
MAU (Media Access Unit)
CNR (Communication and Network Riser)
Game Console
Printer and Office Machine
DVD Player and Recorder
Ethernet Hub
Ethernet Switch
