CS4272-CZZR Integrated Circuit Chip 24-Bit 192kHz Integrated Stereo Audio CODEC

CS4272-CZZR Integrated Circuit Chip 24-Bit 192kHz Integrated Stereo Audio CODEC

Product Description
CS4272-CZZR is a high-performance, integrated audio CODEC. The CS4272 performs stereo analog-to-digital (A/D) and digital-to-analog (D/A) conversion of up to 24-bit serial values at sample rates up to 192 kHz.

Specification

Features

D/A Features
High Performance
– 114 dB Dynamic Range
– -100 dB THD+N
Up to 192 kHz Sampling Rates
Differential Analog Architecture
Volume Control with Soft Ramp
– 1 dB Step Size
– Zero Crossing Click-free Transitions
Selectable Digital Filters
– Fast and Slow Roll Off
ATAPI Mixing Functions
Selectable Serial Audio Interface Formats
– Left Justified up to 24-bit
– I2S up to 24-bit
– Right Justified 16-, 18-, 20-, and 24-Bit
Control Output for External Muting
Selectable 50/15s De-emphasis

A/D Features
High Performance
– 114 dB Dynamic Range
– -100 dB THD+N
Up to 192 kHz Sampling Rates
Differential Analog Architecture
Multi-bit Delta Sigma Conversion
High-pass Filter or DC Offset Calibration
Low-Latency Digital Anti-alias Filtering
Automatic Dithering of 16-bit Data
Selectable Serial Audio Interface Formats
– Left Justified up to 24-bit
– I2S up to 24-bit

System Features
Direct Interface with 5V to 2.5V Logic Levels
Internal Digital Loopback
On-chip Oscillator
Stand-Alone or Control Port Functionality
