LTC3401EMS Integrated Circuit Chip 1A Synchronous Boost Converter 3MHz Step Up Regulators

LTC3401EMS Integrated Circuit Chip 1A Synchronous Boost Converter 3MHz Step Up Regulators​

Product Overviews

LTC3401EMS is a high efficiency, fixed frequency, step-up DC/DC converter that operates from an input voltage below 1V. LTC3401EMS includes a 0.16Ω N-channel MOSFET switch and a 0.18Ω P-channel synchronous rectifier. Switching frequencies up to 3MHz are programmed with an external timing resistor and the oscillator can be synchronized to an external clock. An external Schottky diode is optional but will slightly improve efficiency.

Specification

Features

Synchronous Rectification: Up to 97% Efficiency
1A Switch Current Rating
Fixed Frequency Operation Up to 3MHz
Wide Input Range: 0.5V to 5V (Operating)
Very Low Quiescent Current: 38µA (Burst Mode® Operation)
2.6V to 5V Adjustable Output Voltage
0.85V (Typ) Start-Up Voltage
No External Schottky Diode Required (VOUT < 4.3V)
Synchronizable Switching Frequency
Burst Mode Enable Control
Antiringing Control Reduces Switching Noise
PGOOD Output
OPTI-LOOP® Compensation
Very Low Shutdown Current: <1µA
Small 10-Pin MSOP Package

Applications
Pagers
Handheld Instruments
Cordless Phones
Wireless Handsets
GPS Receivers
Battery Backup
CCFL Backlights
