BQ296107DSGR Integrated Circuit Chip Overvoltage Protector With LDO Output

Large Image : BQ296107DSGR Integrated Circuit Chip Overvoltage Protector With LDO Output

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	BQ296107DSGR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	WSON-8
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10000 Pieces per Day

Contact Now

BQ296107DSGR Integrated Circuit Chip Overvoltage Protector With LDO Output

Description

Part Number:	BQ296107DSGR	Output Voltage::	4.5 V
Output Current::	2 MA	Operating Supply Voltage::	3 V To 20 V
Maximum Operating Temperature::	+ 110 C	Minimum Operating Temperature::	- 40 C
Highlight:	overvoltage protector IC chip , LDO output integrated circuit , BQ296107DSGR IC chip

BQ296107DSGR Integrated Circuit Chip Overvoltage Protector With LDO Output

BQ296107DSGR is a high-accuracy, low-power overvoltage protector with a 2mA regulated output supply for Li-ion battery pack applications.

Specifications

Function	Battery Protection
Battery Chemistry	Lithium Ion
Number of Cells	2 ~ 4
Fault Protection	Over Voltage
Operating Temperature	-40°C ~ 110°C (TA)

Features

2-series, 3-series, and 4-series cell overvoltage protection (OVP)
Fixed delay timer to trigger FET drive output (3-s, 4-s, 5.5-s, or 6.5-s options)
Factory programmed OVP threshold (threshold range 3.85V to 4.6V)
Output options: active high
High-accuracy overvoltage protection: ±10mV
Regulated supply output with self-disable and/or external enable/disable control
Options: 3.3V, 2.5V, and 1.8V (BQ2961)
Options: 3.3V, 3.15V, 3.0V (BQ2962)
Low power consumption ICC ~ 4µA (VCELL(ALL) < VPROTECT)
Extra low power consumption with reg output disabled, ICC ~ 1.2µA
Low leakage current per cell input < 100nA
Small package footprint
8-Pin WSON (2mm × 2mm)

Applications

Notebook PC
Ultrabooks
Medical
UPS battery backup
