MIC2026-1YM-TR Integrated Circuit Chip High Side MOSFET Switches SOIC8 Power Switch IC
MIC2026-1YM-TR is high-side MOSFET switches optimized for general-purpose power distribution requiring circuit protection. MIC2026-1YM-TR is internally current limited and have thermal shutdown that protects the device and load.
Specification
| Switch Type |
General Purpose |
| Number of Outputs |
2 |
| Ratio - Input:Output |
1:2 |
| Output Configuration |
High Side |
| Output Type |
N-Channel |
| Interface |
On/Off |
| Voltage - Load |
2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) |
Not Required |
| Current - Output (Max) |
1.25A |
| Rds On (Typ) |
90mOhm |
| Input Type |
Non-Inverting |
| Features |
Slew Rate Controlled, Status Flag |
| Fault Protection |
Current Limiting (Fixed), Over Temperature, UVLO |
| Operating Temperature |
-40°C ~ 85°C (TA) |
| Mounting Type |
Surface Mount |
| Supplier Device Package |
8-SOIC |
| Package / Case |
8-SOIC (0.154", 3.90mm Width) |
Features
- 140mΩ maximum on-resistance per channel
- 2.7V to 5.5V operating range
- 500mA minimum continuous current per channel
- Shortcircuit protection with thermal shutdown
- Thermally isolated channels
- Fault status flag with 3ms filter eliminates false assertions
- Undervoltage lockout
- Reverse current flow blocking (no "body diode")
- Circuit breaker mode (MIC2076)
- Logic-compatible inputs
- Soft-start circuit
- Low quiescent current
Applications
USB peripherals, General purpose power switching, ACPI power distribution, Notebook PCs, PDAs, PC card hot swap
