ME2005602311011 Connectors Mini Cool Edge 0.60mm Card Edge Connectors 56POS

ME2005602311011 Connectors Mini Cool Edge 0.60mm Card Edge Connectors 56POS
ME2005602311011 Connectors Mini Cool Edge 0.60mm Card Edge Connectors 56POS

Large Image :  ME2005602311011 Connectors Mini Cool Edge 0.60mm Card Edge Connectors 56POS

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: ME2005602311011
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 56POS
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

ME2005602311011 Connectors Mini Cool Edge 0.60mm Card Edge Connectors 56POS

Description
Part Number: ME2005602311011 Number Of Positions: 56 Position
Pitch: 0.6 Mm Current Rating: 1.1 A
Number Of Rows: 2 Row Operating Temperature Range: -40°C To +85°C
Highlight:

0.60mm card edge connectors

,

56 position edge connectors

,

mini cool edge connectors

ME2005602311011 Connectors Mini Cool Edge 0.60mm Card Edge Connectors 56POS
Product Description
ME2005602311011 is 0.60mm, Mini Cool Edge Card Edge Connectors - Storage and Server connector, EDSFF, 56 signal pins, 1x1, Gen 4, Press-fit, Orthogonal.
Specification
Series Mini Cool Edge 0.60mm
Gender Female
Number of Positions/Bay/Row 28
Number of Positions 56
Card Thickness 0.062" (1.57mm)
Number of Rows 2
Pitch 0.024" (0.60mm)
Read Out Dual
Mounting Type Through Hole, Right Angle
Termination Press-Fit
Contact Material Copper Alloy
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Contact Type Cantilever
Color Natural
Operating Temperature -55°C ~ 105°C
Material - Insulation Thermoplastic
Features
  • Signal pin pitch at 0.60mm with current rating of 1.1A, up to 12 pins for power application
  • Signal pins options from 56, 84, 140, 168, 280
  • Customization of pin count upon request
  • Small form factor
  • Discrete pin design
  • Supports 1.6mm thick mating board, 1.97mm, 2.36mm option upon request
  • Hybrid & power individual options from 4C-HP, 4 power pins and 2 power pins available
Applications
  • Communications
  • Baseband
  • Commercial Systems
  • Networking
  • Radio Units
  • Data
  • High-end Computing System
  • Server and Storage Systems
